Display
|
15.6" Medical Grade FHD LED Panel 1920x1080, 350 Nits (Optional 500 Nits)
|
CPU Support
|
11th Generation Intel Core i3/i5/i7 Processors
|
Memory
|
2x DDR4 SO-DIMM Sockets, Populated up to 64GB
|
Operating System
|
Windows 11, Windows 10, Windows IoT, Linux
|
Video & Graphics
|
Intel Iris Xe Graphics
|
Touch Screen
|
PCAP Multi-Touch with Optional Antiglare Technology
|
Networking
|
2x 2.5 Gigabit (Gbe) LAN
|
Wireless
|
Intel Tri-Band WiFi 6E 802.11ax, 802.11 a/b/g/n/ac, + Bluetooth 5.2
|
Expansion Slots
|
1x mPCIe Full-size slot
1x M.2 E Key Short Slot for PCIe or USB Interface
|
HDD Support
|
1x 6Gbps Serial ATA III Port
1x M.2 M Key for NVMe SSD
|
TPM
|
Version 2.0 Standard. Optional: Version 1.2
|
Power Supply
|
Medical Grade Power Supply with Universal input: 100~240V AC, 50-60Hz | Output: 19V
12V/24V Support with Optional DC Converter
|
IP Rating
|
IP65 Sealed Front Bezel and IPX1 Back Cover
|
Pressure
|
700 to 1060hPa (0~3000 meters)
|
DC Power Out
|
Optional: Power Module with 26 Watts of Power Available for External Devices
|
Dimensions
|
14.85" x 9.85" x 1.69" (L,W,D)
|
Weight
|
6.6 lbs without base stand
|
Wall Mount
|
Supports 100mm VESA mounting holes
|
Environment
|
Operating Temperature: 0°C~35°C
|
Relative Humidity
|
10%~90% (non-condensing)
|
Certifications
|
UL60601-1, cUL60601-1, IEC60601-1, IEC60601-1-2 4th Edition, EN60601-1, IEC62368-1 electrical safety, FCC class B, CE, Energy Star, RoHS, WEEE, REACH
|
I/O Ports
|
4x USB 3.2 Gen1
1x USB-C (10Gbps) | Supports 15W Power Delivery, 5V/3A
1x RS232/422/485
1x Display Port
|
Audio
|
Realtek High Definition Audio. One built-in 3.0 watt speaker.
One combination jack for Audio Line Out and Microphone.
|
Warranty
|
3 Years* Standard with Optional Plans up to 5 Years
|
|
Notes:
*Only for US-based customers.
|
